Building a GenAI cost supervisor agent in Databricks

How we turned Databricks System Tables into a knowledge base for an AI agent that answers any GenAI cost questions on demand.

We built a GenAI cost dashboard. Six KPI counters, twelve charts, four detail tables. It tracked spend by service, user, model and use case. It measured governance gaps. It computed the cost per request. The first feedback we got was, “interesting, but hard to see the value when it’s so vague.”

The critique was right, but speaks to the fact that fundamentally a dashboard gives you one fixed view. What happens when you want answers to pointed questions that extend beyond the prebuilt capabilities of the dashboard, such as:

• “How much did my team spend on GPT-5.2 last week?”
• “Which endpoint should I tag first to fix our chargeback gap?”
• “What would we save if we moved simple queries from GPT-5.2 to Sonnet?”
• “Are errors getting worse? What’s that costing us?”

No dashboard is going to be able to anticipate every question, but an AI agent can answer any of them, if it has the right knowledge layer to refer to. That’s when it hit us. All the SQL queries we wrote for our dashboard are actually much more than chart definitions—they’re analytical patterns. If we registered them as Unity Catalog functions and gave an agent access to them, then every user could have access to a personal GenAI cost analyst.

There is no code required beyond the initial function registrations notebook, which you can find here. The entire agent runs in AI Playground, Databricks’ built-in interface for prototyping tool-calling agents.

Import and run the accompanying notebook. It creates a schema, registers all 20 Unity Catalog SQL functions with CREATE OR REPLACE FUNCTION and runs tiered smoke tests to validate each function against your actual data.

You’ll notice there are more than 20 functions available for you to register in the notebook. Currently, the agent supervisor configuration is limited to 20 tools, so we’ve included a few extra functions operating an AI gateway enabled inference tables to help deduce latency and performance insights by endpoint and across your workspace.

Set the following three widgets before running the notebooks:

• Catalog: your Unity Catalog name (e.g. main)
• Schema: where to register functions (e.g. genai_supervisor)
• payload_table: inference table path, if you have one (optional, only for Tier 3 functions not covered here)

The notebook includes a validation step to ensure the functions were registered:

You should see at least 20 rows. Each function’s comment is a description the agent reads to decide when to call it.

In your Databricks workspace, navigate to Agents (left sidebar) and select “Supervisor Agent” from the available options. Enter a name, description and begin configuring the agent with the 20 functions we just registered to Unity Catalog.

Note that there is an optional dropdown at the bottom of the configuration page which allows you to enter instructions for your model.

Here is the system prompt we used for our supervisor:

Once all the pieces are in place, you can click on “Create Agent” which will take you to one more build pane where you can edit things before deploying your agent to the playground.

We have created our genai_cost_supervisor, now let's see what it can do.

Below is a table of functions that the agent has access to via the knowledge layer. Each function is registered in Unity Catalog with a COMMENT that tells the agent when to use it. Every function takes a lookback_days parameter and returns a table.

All 20 of these require only Tier 1-2 prerequisites: billing and serving info from System Tables (not AI-Gateway enabled inference tables). You can enable those and configure the agent since those additional functions based on inference tables are included in the notebook.

One of the more interesting parts of the knowledge layer is in the attribution section since it bridges billing data (dollars) with usage tracking data (tokens). Here’s the challenge:

• Billing (system.billing.usage) tells you the endpoint cost per day: total DBUs x list price. This is a great start, but it doesn't break down the cost by model or user, which is what you need in order to take action.
• Usage tracking (system.serving.endpoint_usage) tells you who uses which model and how many tokens were consumed. But it doesn’t associate dollar amounts with users or models.

The genai_user_model_cost bridges the gap with token-share allocation. Each request computes the share of each user/model combination out of the total tokens consumed per endpoint. It then multiples that by that day’s endpoint cost:

Allocated_cost = endpoint_daily_cost x (user_model_tokens / total_endpoint_tokens)

This gives you two derived metrics:

• Allocated spend: How much of the endpoint cost is attributable to a specific user/model pair.
• Cost per 1k tokens (approx): The effective cost rate for each model, letting you answer questions like “is GPT-5.2 actually more expensive per token, or just used more?”

The SQL that powers this uses a three-CTE pattern:

• endpoint_cost (from billing)
• user_tokens (from usage tracking joined to served_entities for model metadata)
• totals (as the denominator)

The final SELECT does the proportional allocation. This means it isn’t an exact value, a token-weighted approximation, but it’s far better than treating every endpoint as a black box. It also correctly reflects AI Gateway features, like fallbacks and traffic splitting. If a request falls back from GPT to Claude, then the usage tracking table records it under Claude’s served_entity_id, so the cost allocation follows the actual model that served the request.

Everything that follows is from the AI Playground. The agent has access to all 20 UC functions as tools and decides which to call, interprets the results and responds in natural language.

Below you can see a few examples of prompts and responses that showcase the agent’s capabilities on a mock workspace. The final two show mutli-function chaining, the capability that really separates an agent from a dashboard.

Agent response:

This is the entry point. The agent returns total spend broken down by model, requests and users to help you see what's driving the bill. A dashboard would show the same number, but the difference is in what happens next: you can follow up with “break that down by team” without navigating anywhere else.

Notice how the Agent is already drawing key observations from the results, even alerting us to a dormant endpoint which could be a shut down candidate. Let's go to the next prompt.

Reads custom_tags[‘team’] from billing and rolls up cost per team with an (untagged) bucket. This is the chargeback view. If the untagged bucket dominates, like it does in our example below, then the agent doesn’t just show an empty chart. It explains the gap and offers to show you which endpoints to tag first.

Agent response:

We can also see that it prompts the user with both clear next steps and other relevant metrics to help increase the tagging coverage. We can also ask things like “Which endpoints should I tag first to fix our chargeback gap?” to get a list of untagged endpoints ranked by spend, with the agent computing marginal impact.

Now let’s ask it something which triggers a multi-function chain of thinking.

Here the agent is able to identify and extrapolate using multiple tools in parallel to arrive at the answer. In this case, the agent returns a prioritized list of actions.

Agent response:

The AI playground is a prototyping environment. Moving to production means deploying the agent as a governed, monitored endpoint that teams can rely on for recurring cost reviews and ad-hoc analysis.

The AI Playground’s export dropdown includes a Databricks Apps option that generates a complete deployable project from your current session: the model, the UC functions you selected as tools and the system prompt.

When you click Export → Databricks Apps, you're asked to select an MLflow experiment. This is the observability layer for your production agent. Every interaction with the deployed agent—every tool call, every response—gets recorded as a trace in this experiment. It's where you go to debug bad answers, compare agent versions and run evaluations. Create one called something like agent-cost-supervisor and treat it as the agent’s flight recorder. This is very important when you go to deploy because this will act as your main debugging interface on the deployed version.

When you first deploy to Databricks Apps, the transition from Playground to deployed model in production is largely dependent on the sophistication of your agent. MCP servers are more common and arguably easier to implement since they require fewer changes to the agent code itself. However, for fully deterministic patterns in the deployed agent, registered UC functions are the obvious choice.

The exported project follows the architecture that Databricks recommends for production agents (which you used to have to create yourself in the legacy version):

• Agent framework: Your agent’s code lives in agent.py, using the OpenAI Agents SDK (or any framework). The key is wrapping your agent with MLflow’s ResponsesAgent interface which gives you compatibility with AI Playground, Agent Evaluation, tracing and monitoring.
• Tool connection: The agent connects to your UC functions via Databricks MCP servers, which handle tool discovery, execution and security. This is the production pattern: an evolution from the UCFunctionToolkit import you’d otherwise have had to use in a notebook—however for this experiment we are going to wrap our functions in DatabricksFunctionsClient.
• Serving layer: MLflow Agent Server provides an async FastAPI server with an /invocations endpoint, built-in tracing, streaming responses and a production-ready chat UI with Databricks authentication.

Which path to choose:

Building on Unity Catalog means governance comes for free regardless of deployment path:

Function-level permissions: GRANT EXECUTE ON FUNCTION genai_supervisor.genai_total_spend TO finance_group. In this way we can restrict which functions/tools specific roles can use.

What’s more, Databricks has a new feature in public preview called Agent Framework: On Behalf of User Authorization. In the past, and even now for large amounts of use cases, we’ve been limited to m2m in Databricks Apps when it comes to authentication. When you create a new Databricks App it creates a service principal for that app and then you grant permissions to the service principal to allow it to execute on your Databricks workspace.

This is good in a pinch, but you lose the fine-grained access control that comes with user specific authorization, meaning that different users using the same app (service principal) effectively have the same permissions. That is now different. With the new feature, the permission levels are applied all the way down to the model, so you can apply fine-grained permissions on the model responses/tool execution itself.

The agent monitors the GenAI cost, but what monitors the agent? This is where MLflow experiments become especially important. The experiment becomes our primary observability surface. Every agent interaction is recorded as a trace recording keeping track of which tools were called, what results got pulled back and how the agent composed its response. That way, when we go to diagnose the accuracy of an agent or why in particular an answer is wrong it can trace it back to:

• The function itself (bad SQL for example)
• The tool selection (the wrong function was called)
• The synthesis of the response (both the function and tool selection were correct but its analysis of the results was wrong)

Bonus: meta-monitoring. Thanks to the analytical patterns exposed by our UC functions, the agent’s own token consumption shows up in system.serving.endpoint_usage. So the cost supervisor’s own cost is visible and usable by the supervisor agent itself!

The Databricks Apps template also includes evaluation code out of the box (agent_server/evaluate_agent.py). The template evaluates _agent.py using MLflow’s evaluation framework (mlflow.genai.evaluate). It is used to evaluate the relevance and safety of your agent’s responses. Under the hood, this is powered by built-in LLM judge scorers- not traditional ML metrics.

LLM Judges are a type of MLflow scorer that uses LLMs themselves for quality assessment. While code-based scorers use programmatic logic, judges leverage the reasoning capabilities of LLMs to make quality assessments for criteria like safety, relevance, correctness and groundedness.

The template specifically uses the MLflow 3 scorers API. The built-in judges available are:

• Safety: Checks for harmful or unsafe content
• RelevanceToQuery: Does the response actually address the user’s question
• Correctness: Factual accuracy (requires ground truth)
• RetrievalGroundedness: Is the response grounded in retrieved context (for RAG)
• RetrievalSufficiency: Did the retrieval fetch enough relevant context (requires ground truth)
• Guidelines: Custom pass/fail criteria you define in natural language
• ExpectationGuidelines: Per-example pass/fail criteria

The code for which looks like this:

By default, each Judge uses a Databricks hosted LLM designed to perform GenAI quality assessments. So you're not paying to run these through your own endpoint- Databricks hosts the Judge models.

In particular, the GenAI cost supervisor agent we built is primarily used for calling tools against structured data so the retrieval-focused Judges (RetrievalGroundedness,RetrievalSufficiency) won’t make much of a difference here. The ones that mean the most to us are RelevanceToQuery, Safety and potentially Guidelines where you define the custom criteria like “the agent must always call a tool before stating cost figures” or “the agent must format currency values with dollar signs.”

If necessary, you can also write fully custom code-based scorers with the @scorer decorator for deterministic checks: things like varying the agent actually invoked the expected UC function, which you can inspect from the MLflow trace.

One of the strongest arguments for the UC function approach over text-to-SQL agents is that it structurally eliminates SQL injection from the pattern. Every one of our functions has the SQL hardcoded at CREATE FUNCTION time. The agent can’t write SQL- it can only call genai_total_spend(lookback_days → 30) and pass type parameters. The parameter is an INT, not a string that gets concatenated into a query. There’s no vector for DROP TABLE billing.usage;—because the agent never has to construct the SQL itself. It's the difference between a parameterized stored procedure and a raw query builder.

Compare this paradigm to less deterministic text-to-SQL agents (like Genie or custom LLMs) where the model generates almost arbitrary SQL at runtime. Those have a real injection surface where a prompt injection could trick the model into generating a DELETE or UPDATE statement and end up querying tables outside the intended scope.

We started with a dashboard, but quickly realized the value of the same analytics patterns exposed by the SQL we wrote could be used to create an agent with a deterministic, maintained and safe knowledge layer.

The 20 UC functions, which you can register in your own Unity Catalog instance using the notebook, encode every cost formula, governance check and attribution method from the dashboards only as tools an agent can use to compose, chain and reason about. When someone asks, “What should I fix first?” the agent calls four functions and ranks the results by dollar impact. No dashboard can do that out of the box.

The UC function architecture also makes this pattern well suited for production use cases. In particular, when it comes to safety, we found that fixing the SQL at registration time and limiting the agents ability to edit the function to the parameters themselves, there is no surface through which SQL can be injected, no hallucinated queries and no risk of the model inventing a join that silently miscalculates cost allocation. The cost math is locked in the functions. The agent reasons about the results, not the queries.

On top of that, because everything runs on Unity Catalog, the governance is intrinsic to the functions themselves. Function-level permission controls who can ask which questions. Data access inheritance means users get analytical results without touching raw billing tables and every interaction is traced to its own MLflow experiment!

This, combined with the new “Deploy to Databricks Apps,” makes the path to production shorter than before: OAuth, streaming, chat UI and tracing all wired up for you without having to manually do the work yourself in a notebook.

As your AI workloads grow in sophistication, the tools you use to manage and budget them can’t stay stuck on static dashboards. These tools need to reason, chain and adapt alongside the systems they govern.
